Clock Receiver with Dual Output and Integrated Minute Mechanism – For Dials up to 90 cm
Receivers for driving the hands of outdoor clocks, suitable for dials up to 90 cm in diameter. Equipped with dual outputs for hand movement and an integrated minute mechanism. Available for 110 V or 220 V power supply. Available bushing diameters: 46 mm, 68 mm, 81 mm.
These clock receivers are designed to move the hands of outdoor clocks installed on bell towers, public buildings, schools, railway stations, and similar structures. They receive impulses from a master clock every 60 seconds and transmit them to the clock hands.
They are suitable for clock dials up to 90 cm (35.4 inches) in diameter and feature dual outputs for hand movement. They come with an integrated minute mechanism and are available for both 110 V and 220 V power supply.
Bushing available: 46 mm, 68 mm, 81 mm.
Technical Characteristics
- Dial diameter: max 90 cm (2.9 ft)
- Outputs: 2 parallel
- Power: 220-230 VAC, 50/60 Hz, 9.5 W (RIC1004023-24-25); 110/115 VAC, 50/60 Hz, 3.5 W (RIC1004015-16-17)
- Functioning: minute inversion phase
| Power Supply | 220 V or 110 V |
| Bush|Shaft | 46mm or 68mm or 81mm |
| Diameter dial | max 90 cm (2,9 ft) |
| Frequency [Hz] | 50 Hz, 60 Hz |
| Engine power [w] | 9.5 W, 2.7 W |
| Functioning | Minute inversion phase |
Product weight: 0.0 kg
Product volume: 0.0 m³
SKU:
